Garmin ECHOMAP UHD2 75cv with Navionics+ UK, Ireland and Northwest mainland Europe Coast Marine Chart

Product Code: GEU275CV

Garmin ECHOMAP UHD2 75cv chartplotter features a 7-inch display with keypad interface, located to the right hand side of the display.

The Garmin ECHOMAP UHD2 75cv when purchased from ActiveGPS comes preloaded with Navionics+ marine charts for the United Kingdom, Ireland and Northwest mainland Europe coast.

The Garmin ECHOMAP UHD2 75cv supports two types of sonar: Garmin traditional and ClearVu scanning sonar when connected to a compatible transducer. To enable sonar views a transducer (sold separately) is required. Learn more about Garmin transducers.

Garmin ECHOMAP UHD2 75cv features built-in WiFi connectivity which enables you to pair the chartplotter with your smartphone or tablet for remote access to the OneChart feature, smart notifications, software updates, Garmin QuickDraw Community data and more.




Garmin ECHOMAP UHD2 75cv with Navionics+ UK, Ireland and Northwest mainland Europe Coast Marine Chart - £539.99


Deliveries

We offer UK, Europe and Worldwide deliveries. We despatch orders at 4:30pm on Monday, Tuesday, Wednesday, Thursday and Friday. We need to receive your order on those days by 3:00pm. When possible we may despatch orders received after that time. No orders are despatched on Saturday, Sunday or Bank Holidays in England and Wales.

We offer FREE UK delivery* on all orders of £50.00 or more, plus next working day and guaranteed Saturday delivery options. Click here for further info. All options also appear at the basket pages. *Excludes Northern Ireland for chartplotters, fishfinders, etc. Please contact us for courier cost to dispatch to Northern Ireland prior to placing your order.


Garmin ECHOMAP UHD2 75cv chartplotter features a bright, sunlight readable 7-inch display with keypad interface, located to the right hand side of the display.

The Garmin ECHOMAP UHD2 75cv when purchased from ActiveGPS is preloaded with Garmin Navionics+ marine charts with coverage for United Kingdom, Ireland and Northwest mainland Europe coast.

The free to use ActiveCaptain app provides a connection to your Garmin ECHOMAP UHD2 75cv device. Via your mobile device with the ActiveCaptain app, you can download, purchase, and update maps and charts. You can use the app to easily and quickly transfer user data, such as waypoints and routes, connect to the Garmin Quickdraw Contours Community, and update device software. You can also plan your trip from the app.

You can connect to the ActiveCaptain community for up-to-date feedback on marinas and other points of interest. The app can push smart notifications, such as calls and texts, to your chartplotter display when paired.

Take control of the most powerful and efficient trolling motor available, route it to waypoints, follow tracks and more from the screen of the Garmin ECHOMAP UHD2 75cv chartplotter.

Add a Garmin Transducer

When connected to a compatible transducer, the Garmin ECHOMAP UHD2 75cv chartplotter can be used as a fishfinder. The Garmin ECHOMAP UHD2 75cv features built-in support for two types of sonar: Garmin traditional and ClearVu scanning sonars.

Different sonar views can help you view the fish in the area. The sonar views available vary depending on the type of transducer and sounder module connected to the Garmin ECHOMAP UHD2 75cv chartplotter.

There are four basic styles of sonar views available: a full-screen view, a split-screen view that combines two or more views, a split-zoom view, and a split-frequency view that displays two different frequencies. You can customise the settings for each view in the screen. For example, if you are viewing the split-frequency view, you can separately adjust the gain for each frequency.

For more information about which transducer is best for your needs, please complete our online transducer form. Alternatively, if you know which transducer your require (we do however recommend that you complete our online form to find the perfect transducer) you can view the comprehensive range of transducers available buy from ActiveGPS. Pictured below, transom mounted transducer, thru-hull transducer and in-hull transducer.

Please note: a Garmin transducer is NOT included with the original purchase of the Garmin ECHOMAP UHD2 75cv.

Optional Advanced Garmin Marine Charts

The Garmin ECHOMAP UHD2 75cv when purchased from ActiveGPS comes preloaded with Garmin Navionics+ marine charts with coverage for the United Kingdom, Ireland and Northwest mainland Europe coasts - see coverage of preloaded Navionics+ marine chart.

Additional Garmin Navionics Vision+ and Garmin BlueChart g3 Vision HD marine charts with more detailed information (than the standard preloaded Garmin Garmin Navionics+ marine charts) e.g. high resolution satellite imagery of harbours, and ports are among other premium features are also available to buy from ActiveGPS and use with Garmin ECHOMAP UHD2 75cv chartplotter.

Pictured below: screenshots from the latest Garmin Navionics Vision+ series.


Garmin ECHOMAP UHD2 75cv Features

‣7-inch WVGA, TN screen chartplotter
‣Keypad interface
‣Preloaded with Garmin Navionics+ marine charts for the United Kingdom, Ireland and Northwest mainland Europe coast
‣Supports a variety of Garmin transducers for two types of sonar: Garmin traditional and ClearVu scanning sonars (transducer sold separately)
‣WiFi connectivity between compatible ECHOMAP UHD2 chartplotters makes it easy to share information and data
‣Built-in WiFi connectivity pairs with the free ActiveCaptain app
‣What’s under the water looks even better with high-contrast vivid colour palette
‣Quick-release tilt/swivel mount for fast and easy mobility
‣Waterproof to IPX7
‣Supports optional Garmin Navionics Vision+ and Garmin BlueChart g3 Vision HD marine charts, both of which have premium features
‣2 year manufacturers guarantee


Installation

The Garmin ECHOMAP UHD2 75cv comes supplied with Garmin tilt/swivel mount with quick release cable. The tilt/swivel mount surface mounts against most flat surfaces on your boat. In addition and as an alternative flush mounting option, a flush mount kit is also included. Powering the Garmin ECHOMAP UHD2 75cv comes from the supplied Power/data cable.

Chart Coverage

The Garmin ECHOMAP UHD2 75cv marine fishfinder/chartplotter combo is preloaded with Garmin Navionics+ marine charts with coverage for the United Kingdom, Ireland and Northwest mainland Europe coast (see chart coverage below). The preloaded Garmin Navionics+ marine chart includes 1 year subscription for daily updates, raster cartography and more.

Please note: The Garmin ECHOMAP UHD2 55cv is preloaded with Navionics marine charts. If you already own or add Garmin BlueCharts while these are compatible the Navionics charts will automatically be displayed for the included coverage (see chart coverage below). Therefore, the default will be always for the Garmin ECHOMAP UHD2 55cv to display the Navionics charts in these waters, even if you purchase the latest or later version of Garmin BlueCharts marine charts. If you own or use for example a different region e.g. Garmin BlueChart g3 Vision Iceland to Orkney, you will have no issue seeing and using the added Garmin BlueChart.

What's in the box? (when purchased from ActiveGPS.co.uk)

‣Garmin ECHOMAP UHD2 75cv with Navionics+ UK, Ireland and Northwest mainland Europe coast marine chart
‣Power/data cable
‣8-pin to 4-pin transducer adapter cable
‣Tilt/swivel mount with quick release cradle
‣Flush mount
‣Hardware
‣Documentation


Garmin ECHOMAP UHD2 75cv Accessories

Looking for accessories and spares for the Garmin ECHOMAP UHD2 75cv? Accessories available to purchase include replacement protective cover, 4-pin power/data cable and tilt/swivel mount. Pictured below are a few of the other accessories that arecompatible and will enhance the functionality and usability of the Garmin ECHOMAP UHD2 75cv chartplotter. View all Garmin ECHOMAP UHD 75cv accessories.

Garmin ECHOMAP UHD2 75cv Protective Cover

£14.99

‣Heavy duty 7-inch cover fits the Garmin ECHOMAP UHD2 75cv fishfinder head unit snugly, protecting the screen when not in use.


Garmin ECHOMAP UHD2 75cv 6-pin to 4-pin Sounder Cable

£21.99

‣Connect your Garmin ECHOMAP UHD2 75cv fishfinder with a 4-pin connection to a dual beam transducer with an 6-pin connection.


Garmin ECHOMAP UHD2 75cv 4-pin to 12-pin Sounder Cable

£21.99

‣Connect your Garmin ECHOMAP UHD2 75cv chartplotter with a 12-pin connection to a transducer with an 4-pin connection.



Garmin ECHOMAP UHD2 75cv Technical Specification

‣Technology: GPS, WiFi
‣Display: WVGA, TN display (800 x 480 pixels)
‣Display size: 6.1-inch x 3.4-inch,  (109mm x 66mm)
‣Battery: None
‣Mounting options: Bail mount or flush mount
‣Waypoints/favourites/locations: 5,000
‣Navigation routes: 100
‣Track Log: 50,000 points, 50 saved tracks
‣Preloaded with Garmin Navionics+ marine chart with coverage of UK, Ireland and Northwest mainland Europe coast
‣Built-in memory: None (cannot load maps to internal memory)
‣SD card slot: 1 microSD card; 32 GB maximum size
‣Garmin radar compatible: No
‣Garmin sonar compatible: Yes
‣Traditional sonar: Built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
‣ClearVu sonar: Built-in 260/455/800 kHz
‣Waterproof: Yes, IPX7
‣Dimensions: Width - 232mm, Height - 143mm, Depth - 67mm
‣Weight: 700grams
‣Guarantee: 2-year
Garmin ECHOMAP UHD2 75cv manual

Manual requires Adobe Acrobat Reader
Download a free copy here

This product is a sophisticated electronic device which requires that you read, understand, and act upon the information given in the instruction manual (usually available via the above 'manual' link). You will need internet access and, in accordance with the manufacturers’ recommendations, regularly seek out and accept all firmware or software updates offered by the manufacturer. All GPS devices need to ‘see’ the satellites in the sky. Therefore you will need to know that your vehicle does not have glass that will block or impede the GPS signal.

Updates to this product are via the internet. At this product page we state compatibility with specific versions of current internet connection devices, for example: PC, laptop, MAC, smartphone etc. The Consumer Contract Regulations allow you 14 days, from receipt of purchase, to check compatibility with your internet connection device/s. If you choose to replace or update your PC, MAC etc. neither we nor the manufacturer will be responsible if the new/replacement Operating System (OS) is not compatible with the purchased product.
